Description
Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
Features 1 x HDMI input that is replicated to 4 x HDBaseT™ outputs
Features 1 x HDMI loop out for integrating local displays or cascading to multiple devices
Supports 4K 60Hz 4:4:4 UHD video up to 40m
Independent down-scaling of video input resolutions up to 4K 60Hz 4:4:4 to the following formats*:
– 1080p 60Hz (for screens that do not support 4K)
– 4K 60Hz 4:2:0 (for screens that do not support full 4K 60Hz 4:4:4)
Extends HDMI 1080p up to a distance of 70m over single CAT cable
Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
HDMI audio breakout to both analogue L/R audio and coaxial digital outputs concurrently
Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers
Compatible with the following Blustream HDBaseT™ receivers:
– HEX70CS-RX (recommended for where resolutions up to 4K 60Hz 4:4:4 are required)
– Also compatible with HEX70SL-RX (system will be limited to 4K 60Hz 4:2:0 8-bit maximum)
HDCP 2.2 support
* Please note: downscaling feature does not support 4K 4:2:2 input signals
