Description
Speaker Type – In Ceiling/In Wall 2-Way
Woofer – 6.5″ Fluted Injected Poly
Tweeter – 1″ Aluminum Dome
Frequency – 48 Hz – 24 kHz
Sensitivity – 89db
Butyl Rubber Surround
Sonic Vortex® Ported Transmission Line
Magnetic Bezelless Grille – White; paintable
Low Impedance – 8Ω
25V Taps – 0.2, 0.4, 0.7, 1.3, 2.5 Watts
70V Taps – 1.3, 2.5, 5, 10, 20 Watts
100V Taps – 2.5, 5, 10, 20 Watts
Power Handling – In 8Ω Mode – 5-120W
Connector Type – Four position plug-in screw terminal
Speaker Weight – 7.10 lbs (3.22kg)
Cutout – 8.4″ (214mm)
Diameter – 9.4″ (239mm)
Depth – 6.8″ (172mm)
EZBracket Size – F
Highlights – 25/70/100 Volt Switchable
